Minelab Vanquish 560 Metal Detector – Multi-IQ™ Simultaneous Frequency, Waterproof Metal Detector With Wired Headphones - Supports Wireless Audio

THE VANQUISH 60 SERIES: NEXT-GEN PERFORMANCE IN THE LEGENDARY VANQUISH

The Minelab Vanquish 60 Series redefines what a mid-range detector can do. Designed with Minelab’s exclusive Multi-IQ™ simultaneous multi-frequency technology, it unlocks the power to detect all metals in all soils at the same time. Whether you’re scanning parks, fields, or beaches, the Vanquish 60 Series delivers accuracy, stability, and depth that outperform traditional single-frequency detectors. Built light, collapsible, and rugged with waterproof construction, this series is for treasure hunters who refuse to compromise.

MINELAB VANQUISH 560

the most balanced model in the Vanquish 60 lineup – the minelab vanquish 560 combines user-friendly controls with advanced customization. From wireless audio freedom to detailed discrimination settings, it’s built to give you professional performance without the steep learning curve.

It’s compact, lightweight, and easy to operate, yet powerful enough to handle challenging soils and saltwater environments. With waterproof construction, wireless audio, and a larger V12X coil for maximum coverage, the Vanquish 560 turns every outing into a serious hunt.

KEY FEATURES OF MINELAB VANQUISH 560

• Multi-IQ® Simultaneous Frequency – Detect all metals in all soils at once with superior target separation and depth.

• Waterproof Build (IP68) – Submersible to 5 m (16 ft), ready for rivers, shorelines, and rain-soaked hunts.

• 12" × 9" V12X Double-D Coil – Larger ground coverage and deeper detection compared to smaller stock coils.

• Advanced Control Settings – 30 discrimination segments, 10 sensitivity levels, 4 iron bias settings for precise adjustments.

• Wireless & Wired Audio – Bluetooth LE Audio (LC3 codec), wired headphones, built-in loudspeaker.

• Enhanced Target Feedback – Handgrip vibration, clear target tones, 5-level depth indicator, and easy-to-read target IDs.

• Lightweight & Collapsible – Just 1.26 kg (2.6 lbs), collapses to 79 cm, extends to 142 cm, perfect for travel and storage.

• Rechargeable Lithium-Ion Power – Up to 10 hours runtime on a single charge.

• 3-Year Warranty – Peace of mind backed by Minelab’s global support.

TECHNICAL SPECIFICATIONS OF THE VANQUISH 560

Specification	Details
Search Modes	Beach · Park · Field · User Profile
Operation Frequency	Multi-IQ®
Sensitivity Levels	10 Levels
Noise Cancel	Auto
Wireless Audio	Bluetooth LE Audio (LC3 Codec)
Volume Control	10 Levels
Ferrous Volume	10 Levels
Target Tones	5 Tones
Audio Output Options	Built-in Loudspeaker · Wired 3.5 mm (1/8″) Headphones · Bluetooth LE Audio
Discrimination Segments	30 Segments
Target IDs	Ferrous: –19 to 0 · Non-Ferrous: 1 to 99
Depth Indicator	5 Levels
Iron Bias	4 Levels
Length (Extended/Collapsed)	142 cm (56 in) / 79 cm (31 in)
Weight	1.26 kg (2.6 lbs)
Operating Temperature Range	–10 °C to +40 °C (14 °F to 104 °F)
Storage Temperature Range	–20 °C to +70 °C (–4 °F to 158 °F)
Waterproof Rating	IP68 – Up to 5 m (16 ft)
Display	Monochrome LCD
Display Backlight	Yes
Keypad Backlight	Yes
Flashlight	Yes
Vibration	Yes
Key Technologies	Multi-IQ®, Bluetooth LE Audio (LC3 Codec)
Warranty	3 Years (Control Box and Coil)
Standard Coil	V12X 12″ × 9″ Double-D Elliptical Coil
Supplied Batteries	Internal Lithium-Ion Rechargeable
Supplied Accessories	V12X 12″ × 9″ Double-D Elliptical Coil · ML60 Bluetooth LE Ear Buds
